EmberNET SignalCore 5G

Not every 5G deployment starts with a finished device, sometimes it starts with a module and a host that needs one. SignalCore 5G is built for that: a global-band 5G module (supporting both NSA and SA networking, plus 4G/3G fallback) mounted on an M.2-to-host adapter, housed in a metal case ready for wall or rail mounting. It connects to a host over USB 3.1 (USB 2.0 compatible) for high-speed throughput, and it's compatible with the same module family across several generations, so the host board doesn't need to change even if the cellular module inside does. Positioning comes built in. Multi-constellation GNSS support covers GPS, BeiDou, GLONASS, Galileo, and QZSS, useful for anything that needs to know where it is as well as stay connected. Dual SIM slots (switchable via AT command) add carrier redundancy, and an onboard power switch lets the module draw from the host's USB connection or from a dedicated external supply, depending on how much load the application places on it. Key Features Global-band 5G module (NSA/SA) with 4G/3G fallback Multi-constellation GNSS (GPS, BeiDou, GLONASS, Galileo, QZSS) USB 3.1 (USB 2.0 compatible) host connection Dual SIM slots, switchable via AT command Quad-antenna support Metal case with wall and rail mounting Switchable USB or external power supply Prices start at 2gb for $800 4gb for $1000 8gb for $1400 16gb for $1600 They have the following M.2 SSD or M.2 SATA options: 128 GB( +49.00), 256GB(+59.00), 512 GB(+79.00) and 1 TB (+159.00) .

• $800 / $1000 / $1400 / $1600
  Stock not tracked for this item
